Changes to the Workplace Exposure Standard for Welding Fumes

Safe Work Australia recently announced that Work Health and Safety Ministers have agreed to an immediate reduction in the workplace exposure standard for welding fumes, from an 8-hour time weighted average (TWA) of 5 mg/m3 to 1 mg/m3.

As the exposure standard for welding fumes has been reduced, all necessary controls must be implemented to meet this higher standard.

Weld Australia has established a dedicated hotline to help Australian welders and fabricators who need advice on the changes to the workplace exposure standard for welding fumes. This can be reached via: 1800 212 988.

Call the fume hotline: 1800 212 988

Recommended Actions

Based on the hierarchy of controls, the following actions are recommended:

At-source fume control is recommended to maximise the level of fume captured and controlled as it is generated. Suitable methods include local exhaust ventilation (LEV) such as a hooded fume extractor and/or on-gun fume extraction. Captured fume should be filtered and exhausted to atmosphere, preferably outside the workshop.
Welders also require personal respiratory protection, particularly where the welder's head is likely to be in or near the weld plume. For example, the use of Powered Air Purifying Respirators (PAPRs) offer an excellent measure of protection in most welding situations. Externally air-fed helmets may be preferable or be required in some situations, such as confined spaces where oxygen monitoring is required.
Good overall ventilation throughout the workshop to protect the general workforce.

If in doubt, specialist advice should be sought from an occupational hygienist and fume exposure monitoring undertaken.

The Changes

The change to the workplace exposure standard for welding fumes becomes mandatory once implemented in the WHS/OHS laws in the Commonwealth, states and territories. All states and territories have already implemented this new exposure limit.

Under the model WHS laws, persons conducting a business or undertaking (PCBU) – like an employer – must eliminate or minimise the risks to worker health and safety so far as is reasonably practicable, including those associated with chemical exposure.

A PCBU must also ensure that workers are not exposed to any airborne contaminant above the concentration listed in the Workplace exposure standards (WES) for airborne contaminants (WES list). Welding fumes are a complex mix of hazardous chemicals. Some individual components of welding fumes also have their own WES.

In addition to ensuring workers' exposure to total welding fumes is below the WES, PCBUs must ensure workers' exposure to individual welding fume components is below those respective WES also.

Monitoring must be carried out when employers are unsure if a relevant exposure standard is being exceeded, or where there may be a risk to health. Health monitoring may also be required if workers are exposed to certain substances specified by the WHS Regulations that are likely to cause them harm.

The Controls

The model Code of Practice: welding processes provides guidance to help manage the risks associated with welding, including exposure to welding fumes.

According to Safe Work Australia, there are four things PCBUs can do to help protect workers from exposure to welding fumes:

Identify the hazardous components in welding fumes at your workplace.
1. This can come from air monitoring data or from the safety data sheets for the welding rods, if available.
2. Arrange for air monitoring if you are uncertain which components are produced and whether the relevant WES would be exceeded.
Assess the risk of welding fumes at your workplace.
1. This includes consideration of the processes and work environment, observing the nature of work and consulting with workers about work activities that may lead to fume exposure, as well as reviewing incident reports.
Review the control measures you have in place to eliminate or minimise your workers' exposure to welding fumes.
Talk to your workers and any health and safety representatives (HSRs) about the reduced WES, how it might impact your workplace, including changes to control measures and any training your workers might need.

The History

In recent years, the welding industry has become increasingly aware of the hazards posed by metal fume produced during the welding process. This fume, comprising of microscopic particles of hot metal and gases, poses serious risks when inhaled by welders.

In March 2017, the International Agency for Research on Cancer (IARC) reclassified welding fume from Group 2B Possibly Carcinogenic to Humans to Group 1 Carcinogenic to Humans. Their assessment was subsequently published in IARC's Monograph 118 in July 2018.

IARC through Monograph 118 stated that there is evidence for welding fumes causing lung cancer and limited evidence causing renal cell cancer. Ultraviolet radiation from welding was also evaluated and similarly classified as Group 1 Carcinogenic to Humans in Monograph 118.

Weld Australia's Initiatives to Improve Welder Safety

Welding Safety Resources

Fume Minimisation Guidelines: Welding, Cutting, Brazing and Soldering, which includes all the information required to help protect workers from the hazards associated with welding fumes. This has been revised in line with the changes, and a new edition is now available for free download.

Technical Note 7: Health and Safety in Welding, which gives guidance on health and safety practices in welding, cutting and allied processes such as brazing, soldering, pre- and post- weld material treatments and metal spraying.

Welding Safety Council

Established by Weld Australia in early 2019, the Welding Safety Council provides a forum for industry and legislative safety authorities to discuss issues and work collaboratively to identify solutions. By drawing together key government stakeholders, statutory bodies and industry into a single independent body focused on eradicating welding related injury, the Australian welding industry continues to take a significant steps forward in protecting both the general public and welders.

Safety Training Courses

Weld Australia is currently developing two comprehensive online welder safety training courses. One course is tailored for welders, while the other is aimed at welding engineers and supervisors. These courses cover a raft of activities across a range of welding processes, welding fume safety, and welding in confined spaces, at heights, or in hot and humid conditions. These courses are in the final stages of development and will soon be made freely available via the Weld Australia website.

View the Welding Safety Courses
